The eTrex is a sturdy and straightforward GPS unit that runs off of AA batteries. This means that you never have to worry about charging the device or not being able to keep it powered on multi-day tours. You can load Ride with GPS routes onto the eTrex's included SD card to navigate with this device.
_____________________________________________________________________
Download the Ride with GPS mobile app
_____________________________________________________________________
Use the app's Explore tool to find the best routes in your area, or build a custom trip in our Route Planner on mobile or web.
Export a Route on Mobile
Export a Route on Web
After planning a route on our website, you can export the route GPX file to use on the eTrex 20 & 30.
- While viewing a saved route, click More > Export as File.
- Then click GPX Track.
- If you are a Premium or Basic subscriber, check the box for Include cues as waypoints.
- Select Download .gpx File to start downloading your file.
- Plug your eTrex in to your computer with a USB cable.
- Copy the downloaded file(s) into your eTrex device's GPX folder.
- The eTrex is limited by the number of track points available on the device. If you find that your route has been clipped, you may have to split your route into multiple, shorter routes before downloading new route GPX files and loading them onto your eTrex.
Device Settings
We recommend the following settings for your eTrex 20/30 for an optimal navigation experience.
- GUIDANCE METHOD: ON ROAD FOR DISTANCE
- CALCULATE ROUTES FOR BICYCLE
- LOCK ON ROAD = NO
- OFF ROAD TRANSITIONS = AUTO
- AVOIDANCE SETUP = turn all these to DO NOT AVOID
Navigate with your eTrex
- Go to the WHERE TO? page to select your route.
- Go to TRACKS
- Select the route you wish to navigate
- You'll get a preview of the route on your map. Your installed map card may not have the contour lines installed.
- Click GO to start the navigation
View Cues
- If you want to see the cues for the route, go to the ACTIVE ROUTE on the main page.
- If you selected to Include cues as waypoints when you exported your GPX file, you'll see all the cues (waypoints) for your active route. You will also see High Point and Low Point cues that have been automatically generated by the eTrex 20/30.
- This option cannot be disabled.
- Scroll down and click on a cue to see where it will appear on the map.
- Clicking a cue will show you its location on the map, distance to that point, and an ETA.
- When viewing the map screen, we recommend these two data fields.
- Tap the Menu Button on the left side, then select Change Data Fields:
- DISTANCE TO NEXT - This will tell you how far to the next waypoint.
- WAYPOINT AT NEXT - This will tell you which cue is next.
Pro Tips
- Lithium AA batteries will last much longer than standard alkaline batteries, especially in colder conditions. They're worth the extra money you'll spend for these.
- You can turn off the backlight to conserve power. Note that the screen will stay on, even if the backlight is dimmed or off.
- On some eTrex devices, you can tap the light/power button to see the backlight settings, then move the backlight brightness slider all the way to the left. Consult your device manual for more information about adjusting your backlight.
